Guide to BACA’s Waterjets

Robo SawJet

BACA’s waterjet robotic machines are ideal solutions for applications that require granite and marble cutting. We offer two primary waterjet models: the Roba SawJet 2.0 and Robolution Pro. Each machine is highly efficient, user-friendly, and delivers extreme precision, creating perfect finishes for every cut.

Keep reading to learn about our available waterjet models and how each can transform your marble and granite countertop productions.

Robo SawJet 2.0

Our high-pressure Robo SawJet 2.0 waterjet is our latest version of the original SawJet that helped transform stone fabrication across North America. This ultra-precise granite and marble waterjet features high-pressure coils on all six axes, allowing the robot to move quickly between cuts, and a two-table design, which allows it to work constantly to maximize your countertop production rates. You’ll benefit from fully automated, perfect cuts in less time, with superior safety.

Power Specifications:

  • 480V, 3 Phase, 80 Amps (Robot)
  • 480V, 3 Phase, 100 Amps (Pump)

Water Specifications:

  • 5 GPM at 35 PSI (Saw Water)
  • 4 GPM at 40 PSI (Cutting Water)
  • 2 to 4 GPM at 35 PSI (Pump Cooling)

Air Specifications:

  • 1 CFM at 85 to 100 PSI (Robot)
  • 3 CFM at 60 to 100 PSI (Garnet System)

Robolution Pro

Featuring state-of-the-art PC-based control software and adaptive technologies, BACA’s Robolution Pro waterjet effortlessly handles complex functions like inside corner miter cuts and full-span arcs while simultaneously nesting usable scraps to significantly reduce material wastage.

This low-maintenance waterjet features a high-powered VFD-driven 26-HP saw and works with a 60K PSI jet to cut through granite, marble, porcelain, quartzite, and other ultra-compact slabs smoothly and quickly.

It can also be upgraded with a second cutting table to increase your production output as your company grows.

Power Specifications:

  • 480V, 3 Phase, 80 Amps (Robot)
  • 480V, 3 Phase, 100 Amps (Pump)

Water Specifications:

  • 4 GPM at 40 PSI (WaterJet)
  • 5 GPM at 35 PSI (Saw Water)
  • 2 to 4 GPM at 35 PSI (Pump Cooling)

Air Specifications:

  • 5 CFM at 85 to 100 PSI (Robot)
  • 3 CFM at 60 to 100 PSI (Garnet System)

WaterJet Made Easy

WaterJet Made Easy is BACA’s premier waterjet maintenance program that allows you to focus on maintaining near-ceaseless production.

We provide you with two separate high-pressure intensifiers. When you notice signs that your high-pressure assembly needs servicing, you replace it with the standby unit. This replacement process only requires 15 minutes.

Next, you ship the intensifier unit to BACA Systems in a shipping crate that we provide. Once we receive the shipment, our trained and certified technicians perform general maintenance, repair, and rebuilding as needed. The like-new unit is then shipped back to you, pre-tested, and ready for use.

Learn More About Our Waterjets

BACA Systems is North America’s leading provider of countertop fabrication and stone automation machinery. Since 2014, our team of dedicated experts has continued to expand the fields of waterjet technology, countertop fabrication, system integration, and robotic automation.

Contact our helpful team today to learn more about our flexible and affordable waterjet solutions. We’ll answer your questions and help you determine the best BACA waterjet system to meet your unique needs.
